Key Features & Specifications

•  Audible and Visual alarm when Lift is in operation.
•  2 Nos of Anti-fall device provided to carriage to avoid sudden fall when lifting
•  Motor is of continuous duty.
•  Chain selection will be of 8-10 times more of total load.
•  Lifting and Lowering will done by Gearbox with fail safe brake motor (Make – Nord).
•  UDL capacity : 1000 Kg – 5000 Kg
•  Platform sizes up to 3000 mm x 5000 mm
•  Lift Height up to – 25 mtr
•  Entry Exit : Same, opposite & as per requirement.
